SIUI Smartor

€0.00

Advanced Ultrasonic Testing & Thickness Measurement


Superior Features

  • IP 66 with compact size: 198 (W)* 128 (H) *52 (L) mm

  • Lightweight: 0.9kg only, including battery

  • 5.7" LCD with high resolution 640x480 pixels

  • Adjustable pulse width, negative square wave transmission up to 350V.

  • Operating frequency range: 0.5~20MHz, multiple steps of wide broadband and narrow-band for selection.

  • Easy operation: only a few buttons, intuitive interface and logical menu, support right/left-hand operation, outdoor mode.

  • Conventional UT functions

    Standard functions: Weld, plate and forging test wizards, DAC, Peak memory, AGC (Auto gain control), video record.

    Optional functions: B-Scan, TCG, FFT (probe spectral analysis), CSC (curved surface correction), flat weld simulation, crack height measurement, BEA(back wall echo attenuator), AWS, API 5UE.

  • Thickness measurement functions:

    Standard functions: A-scan thickness measurement (echo to echo mode), Auto-search, velocity measurement, alarm and dataset management.

    Optional functions: CoatMode, B-Scan, MultiLayers, Vpath, TDG and temperature compensation.

  • Specific functions are subject to final order.

Quantity:
Quotation

Advanced Ultrasonic Testing & Thickness Measurement


Superior Features

  • IP 66 with compact size: 198 (W)* 128 (H) *52 (L) mm

  • Lightweight: 0.9kg only, including battery

  • 5.7" LCD with high resolution 640x480 pixels

  • Adjustable pulse width, negative square wave transmission up to 350V.

  • Operating frequency range: 0.5~20MHz, multiple steps of wide broadband and narrow-band for selection.

  • Easy operation: only a few buttons, intuitive interface and logical menu, support right/left-hand operation, outdoor mode.

  • Conventional UT functions

    Standard functions: Weld, plate and forging test wizards, DAC, Peak memory, AGC (Auto gain control), video record.

    Optional functions: B-Scan, TCG, FFT (probe spectral analysis), CSC (curved surface correction), flat weld simulation, crack height measurement, BEA(back wall echo attenuator), AWS, API 5UE.

  • Thickness measurement functions:

    Standard functions: A-scan thickness measurement (echo to echo mode), Auto-search, velocity measurement, alarm and dataset management.

    Optional functions: CoatMode, B-Scan, MultiLayers, Vpath, TDG and temperature compensation.

  • Specific functions are subject to final order.
